HVAC PRE-INSULATED DUCT
OEM & ODM services for all kinds of HVAC duct, PU FOAM and aerosol products
Language
OEM & ODM services for all kinds of HVAC duct, PU FOAM and aerosol products
To keep up with the industry development, all employees of SHANGHAI HAOHAI CHEMICAL CO.,LTD have been doing their utmost to develop new products for days. Fireproof Insulation Panel PIR PU Phenolic Aluminium Foil HVAC Air Ducts developed on the premise of market trends and customer pain points have become the new vane of the industry. SHANGHAI HAOHAI CHEMICAL CO.,LTD have long desired to become one of the most influential enterprises in the industry. At present, we are busy improving our capabilities in product manufacturing, and gathering talents especially technical talents to develop our own core technologies.
| Warranty: | Lifetime | After-sale Service: | Online technical support, Return and Replacement |
| Project Solution Capability: | total solution for projects | Application: | Hotel |
| Design Style: | Modern | Place of Origin: | China |
| Brand Name: | Haohai | Certification: | CE |
Characteristics
• Light, safe, decrease the load of the building.
• Easy to install, shorten the construction period.
• Protect environment, sandwich structure with antioxidant surfaces.
• High performance in heat insulating, can be served in both high and low temperature environment.
• Fireproof, meet the National standard, makes building safe.
• Soundproof, makes a quieter environment.
• No need to leave space for insulation material installing, so that the story height can be reduced.
• Long service life up to 20 years, very low cost in wastage and maintenance.
• Nice appearance.
Haohai duct system including
• Haohai duct panels
• Accessories for Haohai duct
• Training and service for duct installation
• Datasheet of tech & safety for duct installation
• Undertake projects of duct installation
Product Data Sheet
| Smoke temperature |
125°C
|
| Flame height | 15mm |
| Thickness of panel | 20mm |
| Density | 40~69kg/m3 |
| Compressive strength,10% | 0.2MPa |
| Dimension stability | 0.5% |
| Thermal conductivity | 0.021w/m.k |
| Working temperature | -50 to +80°C |
Comparison between Haohai duct and other ducts
| Item |
Haohai duct
|
Zincification duct
|
Fiberglass duct |
XPS
|
|
Thermal
conductivity
|
excellent
|
poor | general | general |
| Weight(kg/m²) |
1.3-1.4
|
8.32 | 8.8 | 1.1~1.3 |
|
Flame Retardancy
|
Phenolic A class
PU B1 class
|
A class | A class | ------ |
|
Service life
|
15~20 years
|
6~7 years | 10~15 years | 15~20 years |
| Contaminant |
Never
|
Yes | Yes |
A little
|
|
Installation speed |
Fast
|
Slow
|
Slow
|
Fast
|
|
Installation effect |
Easy to install, nice appearance, high efficiency | Complex install, low efficiency | Complex install, low efficiency | Easy to install, nice appearance, high efficiency |
| Maintenance | Low | High | High | Low |
Haohai duct satisfies the following standards:
• GB50243-2002
Acceptance standard for construction quality of HVAC works.
• GB50045-95
Criterion of fireproof design of civil tall buildings.
Environment
Inspected by the National Construction Material Test center,
Haohai duct passed the formaldehyde volatilization test, could be applied indoor directly.
• Approved by the National Quality Test Center and China Construction Material Association,
Haohai duct is a stable qualify, safe and environment protective product.
• Inspected by Shanghai quality monitor inspection spot, if s innocuous and a safe product.
• There is no Freon in Haohai duct, and won, t destroy aerosphere.
• As a result of low water absorbability of Haohai duct, it won5 t bring germ in the duct.
Installation Accessories
Various flanges,H bayonet, Hooked hanger bracket, Aluminum shaped disk, Covering angle, G.I.
Square, etc.
Installation
